13.56Mhz 125Khz Dual Frequency 12v RFID Reader Module

100% of buyers enjoyed this product!
19912
Color:
WG26 34 UART
View cart→
Product Description
Shipping & Payment
Product Details


Voltage: DC12V
Current: 40mA
Indicator: Y
Buzzer: Y

Support card: 125kHz, 13.56MHz (ISO 14443A)
Interface: Uart, wg26/34

Size: 47*26*5mm
Temperature: -20-70c
Read card distance: EM4100>8CM
S50 S70 MF1, DESF**, FM1208>5CM
Card reader distance based on card coil and environment.

Wiegand
VCC: DC12V power supply, choose linear power supply for better card reading effect
GND
D1 D0: Wiegand DATA1, DATA0
FOR: Dangling means Wg26, Wire GND Wg34

UART
VCC: DC12V power supply, choose linear power supply for better card reading effect
GND
D0: TX

UART Out data format

Data header

length

Card type

Card number

Bccmt

dataend

0x02

0x09

0x01

SN0-SN3

[Exclusive OR of other data except the end of the data]

0x03

For example, the data received by the serial port tool is 02 0A 02 2E 00 B6 D7 B5 F2 03
The first byte 0x02 indicates the beginning of the data.
The second sector 0x0A indicates that the entire data length is 10 bytes, including data start and data end.
The third sector 0x02 indicates that the card type is EM4100.
The fourth sector to the eighth byte (0x2E 0x00 0xB6 0xD7 0xB5) These 5 bytes represent the card number read, and the fourth sector 0x2E is the hidden card number.
The ninth sector 0xF2 represents the BCC check of the second byte to the eighth byte.
The tenth section 0x03 indicates the end of the data.
